ZKTeco 8 Ports 10/100Mbps PoE Switch

Networking Components ZKTeco 8 Ports 10/100Mbps PoE Switch

ZKTeco 8 Ports 10/100Mbps PoE Switch

Price TBA ৳

Status: Upcoming

Product Code: PR01093

Brand: ZKTeco

Model: PE082-120-C

Features

8*10/100M RJ-45(POE) +2*10/100M RJ-45
Conforms to IEEE 802.3, IEEE 802.3u and IEEE802.3af/at
The max. PoE power output is 15.4 W (IEEE 802.3af )/ 30 W (IEEE 802.3at)
250 meters of PoE transmission distance of power and data (Cat 6)
MDI/MDIX self-adaptation
Store-and-forward switching
Lightning protection

Hotline: 01979234344 | Corporate: 01979234319

Download Brochure

Social Share:

Specification

Description

Reviews

ZKTeco PE082-120-C is an advanced PoE switch providing a network point for data transmission and power supply. It has 8 PoE ports that can
provide standard IEEE802.3af/at power supply through network cables.
Because of the advanced self-sensing algorithm for supplying power over IEEE802.3af/at, the connected PoE or non-PoE standard
equipment is safely protected.

Model Number:	PE082-120-C
Port	810/100M RJ-45(POE) +210/100M RJ-45
Network Protocol	IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/at
PoE	PoE Standard: IEEE802.3af/IEEE802.3at PoE Consumption: Max 15.4 W (IEEE 802.3af )/30 W (IEEE 802.3at) PoE Compatibility: IEEE 802.3af/at self-adaptation Output Voltage: DC48V Power Supply: 1,2+; 3,6-
Network Cable	10Base-T: Cat3 UTP/STP(≤100m) 10Base-T: Cat6a UTP/STP(≤250m) 100Base-TX: Cat5e UTP/STP(≤100m)
Backplane Bandwidth	2Gbps
Packet Forwarding Rate	1.488Mpps
Buffer Memory	448K
MAC Size	2K
Switching	Store-and-Forward
Power Consumption	120W
Supply Voltage	AC100-240V input 52V/2.3A output
Operating Temperature	-20°C to 55°C
Dimensions (LWH)	22012045 (mm)
Net Weight	0.62kg
MTBF	100,000 hours
